Festool 575081 Festool LEX 3 150/5 Compressed Air Eccentric Sander

Festool LEX 3 150/5 Compressed Air Eccentric Sander - (Ref: 575081)

Stops vibrations. Increases efficiency.

Stops vibrations, increases efficiency. With a 5 mm sanding stroke, the LEX 3 150/5 compressed air eccentric sander ensures fast working progress and a high-quality sanding finish, e.g. with the coarse and intermediate sanding of flat surfaces and roundings or repair compounds in the four-step sanding process. Weighing just 1 kg, with minimal vibration values, comfortably low noise levels, a robust and durable motor as well as extremely low compressed air consumption, it is suitable for both automotive applications and kitchen and furniture assembly – for the intermediate sanding of wood, paint and varnish and preliminary sanding of solid surface materials.

• Low compressed air consumption ensures high cost savings
• Low vibration levels and a pleasant operating noise protect the user's health
• Extremely sturdy design ensures a long service life, minimal servicing requirements and high cost savings
• Simplifies permanent dust extraction, guarantees the best working results and protects the user's health when combined with the IAS 3 light hose
• Large 5 mm sanding stroke ensures rapid working progress, a high-quality sanding finish and cost savings
• High-quality FUSION-TEC sanding pad with MULTI-Jetstream principle ensures efficient dust extraction, minimises rework and saves on costs
• Sanding pad brake reduces sanding errors when setting down the machine, thereby avoiding rework and additional costs

• Coarse and intermediate sanding of flat surfaces or curves
• Coarse and intermediate sanding of filler, e.g. in 4-step sanding system
• Intermediate sanding of wood, paint and clear coats
• Preliminary sanding of mineral materials
• Note: an IAS 2/IAS 3 connecting system is required for operation

• StickFix sanding pad Ø 150 mm FUSION-TEC (soft HT)
• operation tool

• Operating pressure (flow pressure) 6 bar
• No. of strokes 20000 min⁻¹
• Eccentric motion speed 10000 min⁻¹
• Sanding stroke 5 mm
• Vibration emission value Ah (single-axle) 2.7 m/s²
• Vibration emissions value Ah (three-axle) 3.9 m/s²
• Air consumption at rated load 290 l/min
• Sound pressure level 72 dB(A)
• Sanding pad dia. 150 mm
• Weight 1 kg
• Sanding: Uncertainty (noise) K 3 dB
• Sanding: Total vibration average, Ah 3.9 m/s²
• Sanding: Uncertainty (vibration) K 2 m/s²
• Sanding: A-weighted sound pressure level, LpA 72 dB(A)
• Sanding: A-weighted sound power level, LWA 83 dB(A)

Festool LEX 3 Owners Manual
