Specification
Fastener type - Collated Screws
Fastener length - 34-36 mm
Collation type - Plastic collated
Shank type fastener - 2/3 coarse
Wire material - Yellow zinc
Point type - Type 17 cut point
Pointangle (nominal) - 23 º
Amount fasteners on strip/coil - 50-50 pieces
Nominal diameter - 4.20 mm
Rotations per minute (RPM) - 3300, 4000, 5000 RPM
Screw diameter - 4.05-4.3 mm
Characteristic yield moment - 3 582.00 Nmm
Characteristic withdrawal parameter paralel - 12.35 N/mm²
Characterist head pull through parameter - 31.30 N/mm²
Characteristic tensile strenght - 4 504.00 N/mm²
Protection level in micron - 3
Service class - 1
Lenght of threaded part - 20.00 mm
Screw recess type - Philips
Screw recess size - 2
Inner threaded diameter - 2.95 mm
Characteristic torsional strenght - 3.47 Nm
Characteristic torsional resistance - 1.47 Nm
Material notification on CE label - Non-alloy steel
